| Filter Types | Bag Type | Disc/ Needle Type | Cartridge Type |
|---|---|---|---|
| Filter Membrane | Hydrophilic PVDF | Hydrophilic PVDF | Hydrophilic PVDF |
| Filter Membrane Support Layer | Polypropylene PP | - | Polypropylene PP |
| Inner Core | Polypropylene PP | - | Polypropylene PP |
| Inner Shell | Polypropylene PP | - | Polypropylene PP |
| Bag-type Housing | Polypropylene PP | Polypropylene PP | - |
| Bag-type O-ring | Silicone Gel | - | Silicone Gel |
| Series Number | Filtration Precision | Upper Connector | Length | Central Tube | Lower Interface | Sealing Ring/Gasket |
|---|---|---|---|---|---|---|
| JHPVDF | 0010=0.1μm | Z = Shaped Sharp Corner | 25=2.5inches | Default = General Polypropylene | D=222 Regular Type | S = Silicone Rubber |
| FJPVDF | 0020=0.2μm | S = Triangular Fins | 05=5inches | H = Stainless Steel | E=226 Regular Type | V = Fluoroelastomer (Viton) |
| 0045=0.45μm | P = Blind Head | 10=10inches | T = Temperature-Resistant Reinforced Inner Liner | DH=222 Outer Lining Steel Rings | Y = EPDM (Ethylene Propylene Diene Monomer) Rubber | |
| 2001=0.2/0.1μm | 20=20inches | EH=226 Outer Lining Steel Rings | F = Nitrile Rubber | |||
| 2020=0.2/0.2μm | 30=30inches | DN=222 Inner Lining Steel Rings | WV = Outer Coating with PTFE (Polytetrafluoroethylene) | |||
| 4520=0.45/0.2μm | 40=40inches | EN=226 Inner Lining Steel Rings | E = Ethylene Rubber |
*Matching Instructions for Pore Size and Series: JHPVDF(0.1, 0.2, 0.45 μm); FJHPVDF(0.2/0.1, 0.2/0.2，0.45/0.2 μm).
For more precision filtration options, please consult with our sales representative.
